Core drilling system DRS250
Core drilling up to Ø 250 mm
The DRS250 drilling system combines simplicity with a large drill diameter range. The drill motor and drill rig complement each other and form a single unit. 2-speed oil bath gearbox insures perfect lubrication in all working positions, as well as optimal torque-to-speed ratio. Compact and lightweight construction guarantees easy handling and user-friendliness. Mechanical overload clutch and integrated PRCD safety switch ensure maximum safety. Optional vacuum plate offers more flexibility in fixing the system. Show more Show less
- Drilling diameter up to 250 mm with 2-speed gearbox.
- Powerful 2.5 kW motor.
- Space-saving fixing option via dowel foot.
| Downloads |
|---|
| Product flyer PDF 168 kb |
| Manual PDF 736 kb |
PREMIUM CDL Wet drill bits
for reinforced concrete (up to Ø 42 mm)
Drill motors up to 3 kW | soft to medium-hard concrete aggregates. Quality tools for the most demanding applications and maximum economic efficiency. Excellent and consistent performance, universal use and smooth core removal. Laser welded segments up to a Ø 300 mm for maximum safety.
- Consistently very fast cutting performance and noticeable smooth running.
- Long lifetime.
| Downloads |
|---|
| Product flyer PDF 7.63 mb |
PREMIUM TGD® CDL Wet drill bits
for reinforced concrete (from Ø 47 mm) | in TGD®-Technology
Drill motors up to 3,5 kW | soft to medium-hard concrete aggregates. Quality tools for the most demanding applications and maximum economic efficiency. Excellent and consistent performance, universal use and smooth core removal. Segmented drill with TGD®-technology and new segment height of 11.3 mm. Laser welded segments up to a Ø 300 mm for maximum safety.
- Consistently very fast cutting performance and noticeable smooth running.
- Long lifetime.
| Downloads |
|---|
| Product flyer PDF 7.63 mb |
CDL-C2 Wet drill bits
for reinforced concrete | in TGD®-Technology (from Ø 82 mm)
Drill motors up to 3 kW | soft to medium-hard concrete aggregates. Quality tools for the most demanding applications and maximum economic efficiency. Excellent and consistent performance, universal use and smooth core removal. Segmented drill from Ø 82 mm with TGD®-Technology and new segment height of 11.3 mm. Laser welded segments up to a Ø 300 mm for maximum safety.
- Consistently very fast cutting performance and noticeable smooth running.
- Long lifetime.
PREMIUM CDM Wet drill bits
for reinforced concrete | in TGD®-Technology (from Ø 82 mm)
Drill motors over 3 kW | medium-hard to hard concrete aggregates. Quality tools for the most demanding applications and maximum economic efficiency. Excellent and consistent performance, universal use and smooth core removal. Segmented drill from Ø 82 mm with TGD®-technology and new segment height of 11.3 mm. Laser welded segments up to a Ø 300 mm for maximum safety.
- Consistently very fast cutting performance and noticeable smooth running
- Long lifetime.
CDXH Wet drill bits
for reinforced concrete
Drill motors over 3.5 kW. Hard to very hard concrete aggregate. Quality tools for the most demanding applications and maximum cost efficiency. Universal use and smooth core removal. New segment height of 11.3 mm for a long lifetime. Laser-welded segments up to Ø 300 mm for maximum safety.
- Very long lifetime
- Consistently very fast cutting performance.
CDXM Wet drill bits
for reinforced concrete
Drill motors over 3 kW. Medium-hard to very hard concrete aggregate. Quality tools for the most demanding applications and maximum cost efficiency. Universal use and smooth core removal. New segment height of 11.3 mm for a long lifetime. Laser-welded segments up to Ø 300 mm for maximum safety.
- Very long lifetime
- Consistently very fast cutting performance.
CD840 Wet drill bits
for reinforced concrete
Drill motors over 3 kW. Soft to medium-hard concrete aggregate. Quality tools for the most demanding applications and maximum cost efficiency. Universal use and smooth core removal. New segment height of 11.3 mm for a long lifetime, new segment geometry for a high stock removal rate. Laser-welded segments up to Ø 300 mm for maximum safety.
- Very long lifetime
- High stock removal rate
- Consistently very fast cutting performance.
CD640 Wet drill bits
for reinforced concrete
Drill motors up to 3 kW. Medium-hard to very hard concrete aggregate. Quality tools for the most demanding applications and maximum cost efficiency. Universal use and smooth core removal. New segment height of 11.3 mm for a long lifetime, new segment geometry for a high stock removal rate. Laser-welded segments up to Ø 300 mm for maximum safety.
- Very long lifetime
- High stock removal rate
- Consistently very fast cutting performance.
CD660 Wet drill bits
for reinforced concrete
Drill motors up to 2.5 kW. Soft concrete aggregate. Quality tools for the most demanding applications and maximum cost efficiency. Universal use and smooth core removal. New segment height of 11.3 mm for a long lifetime, new segment geometry for a high stock removal rate. Laser-welded segments up to Ø 300 mm for maximum safety.
- Very long lifetime
- High stock removal rate
- Consistently very fast cutting performance.
STANDARD CDL Wet drill bits
for reinforced concrete
Drill motors up to 3 kW | soft to medium-hard concrete aggregates. Details: quality tools for everyday use. An impressive drilling speed-lifetime ratio. Universal use, lasting quality. Laser welded segments up to a diameter of 300 mm for maximum safety.
- Quality tool
STANDARD CDM Wet drill bits
for reinforced concrete
Drill motors over 3 kW | medium-hard to hard concrete aggregates. Details: quality tools for everyday use. an impressive drilling speed-lifetime ratio. Universal use, lasting quality. Laser welded segments up to a diameter of 300 mm for maximum safety.
- Quality tool
B1 Wet drill bits
for reinforced concrete
Drill motors up to 2.5 kW. Soft concrete aggregate. Quality tools for everyday use. New segment height of 11.3 mm for improved lifetime. Laser-welded segments up to Ø 300 mm for maximum safety.
- Cost-effective performance and lifetime
- Universal use.
